Air cooled
Minimum Clearance should be 300mm on left,right, and 400mm rear for assuring adequate air flow
Electrical
One dedicated electrical connection is required. Check with local electrician for cord and receptacle specifications if 50 Hz or 60 Hz Equipment is desired
Customization
Product customization may be available upon request
A new advanced system enables the operation easier . Be equiped with automatic, cleaning, sleep and other basic operating functions and a variety of alarm prompts. Rebound pistons—control ice cream making speed Automatic handles homing—press the handles and auto return back.
With the brilliant France Tecumseh compressor , the first dispensing just needs 8-12 minutes and more than 15 cones can be made continuously.
Insulated the heat and trapped the chill, improve efficiency Full & thicker foaming evaporator to ensure perfect refrigeration efficiency.
Our newest air tube has three adjustable holes, big, medium, small; even can be sealed up; not only can it make the high overrun, but also meet the different requirement;
Using temperature sensors to avoid over freezing damage.
Hopper cooling feature is able to keep temperature of the mix at or below 41℉(5℃).
|
Model |
DW138TC/DW150TC/DW165TC |
|
Flavors |
2+1 mixed |
|
Production Capacity |
38L/H 50L/H 65L/H |
|
Mix Hopper |
2*12L |
| Cylinder |
2*2L |
|
Power |
2600W/2800W/3600W |
|
Main Compressor |
1.5HP/2HP/3HP |
|
Cooling System |
Air Cooled |
|
Refrigerant |
R134A,R404A(Standard) / R448A(Option) |
|
Standard
|
Pre-Cooling, Stainless Steel Shell, Automatic Rebound Valve Body
|
|
Options |
Air Pump /Italian Gear Pump / Mixture Agitator / Stainless Steel Handle |
|
Voltage |
220V/380v-50Hz/60Hz |
|
Net Weight / Total Weight(kg) |
178/210kg 197/237kg 197/237kg |
|
Dimension |
540*770*1450mm |
