Air cooled
Minimum Clearance should be 300mm on left,right, and 400mm rear for assuring adequate air flow
Electrical
One dedicated electrical connection is required. Check with local electrician for cord and receptacle specifications if 50 Hz or 60 Hz Equipment is desired
Customization
Product customization may be available upon request
A new advanced system enables the operation easier and more user-friendly with touch screen and infrared remote control.
With compressor 1.25HP Tecumseh, the first dispensing just needs 12-15 minutes and more than 15 cones can be made continuously.
Stand by keeps the whole machine into refrigeration.
The low liquid alarm will sound when the hopper is lack of ice cream mix.
With temperature sensor for low temperature protection.
Hopper cooling feature is able to keep temperature of the mix at or below 41℉(5℃).
|
Model |
DW132TC |
|
Flavors |
2+1 mixed |
|
Production Capacity |
32L/H |
|
Mix Hopper |
2*12L |
| Cylinder |
2*2L |
|
Power |
2200W |
|
Main Compressor |
1.5HP |
|
Cooling System |
Air Cooled |
|
Refrigerant |
R404A(Standard) / R448A(Option) |
|
Standard |
Pre-Cooling, Automatic Rebound Valve Body, Stainless Steel Shell |
|
Options |
Air Pump / Stainless Steel Handle / Mixture Agitator |
|
Voltage |
220V 50Hz/60Hz |
|
Net Weight /Total Weight(kg) |
146 / 175kg |
|
Dimension |
530*750*950mm |
